Magewell Pro Convert NDI Decoder SDI & HDMI
€519,09 Incl. btw€429,00 Excl. btw
Niet op voorraad, check levertijd
Registreer je in onze webshop. We controleren je gegevens en geven je toegang tot gepersonaliseerde kortingen. Crosspoint geeft je graag persoonlijk advies gebaseerd op meer dan 25 jaar ervaring. Bekijk ook andere ndi converters in onze webshop. Lees meer
- ECO friendly webshop
- Persoonlijk advies
- 25 jaar ervaring
- Meer dan 4.000 producten
- Secure payment
- Registreer en ontdek je voordelen
Specificaties
Merk:
Magewell
Beschikbaarheid:
Niet op voorraad, check levertijd
Levertijd:
2 - 3 weken
Gerelateerde producten
Informatie
- Connects baseband presentation or distribution equipment into IP-based media networks
- Supports NDI technology including Full NDI and NDI|HX mode
- Supports streaming protocols including SRT, RTSP, RTMP, UDP, RTP, HLS and HTTP
(
HDMI Output
- HDMI interface: DVI-D 1.0/HDMI 1.4
- Max output: 1920x1080p60
- Delivery videos within 2K at the preferred video format according to the EDID of the connected monitor
- Support YUV BT.601, YUV BT.709 signal
- Support 48KHz 16bits 8-channel audio output
SDI Output
- BNC: SD/HD/3G SDI
- Max output: 1920x1080p60. Supported output formats are:
- 1920x1080p60/59.94/50/30/29.97/25/24/23.98
- 1920x1080i60/59.94/50
- 720p60/59.94/50/30/29.97/25/24/23.98
- 720x576i50
- 720x480i59.94
- Support YUV BT.601, YUV BT.709 signal
- Support 48KHz 16bits 8-channel audio output
- Output SDI signal and transmitted distances are as follows:
Signal Distance SD-SDI 200m 656ft HD-SDI 150m 492ft 3G-SDI 120m 394ft
Decoding Features
- Support decoding 1080p60 streamings of Full NDI, NDI|HX, NDI|HX2, RTSP, HTTP, HLS, RTMP Pull/Push, and MPEG-TS over UDP/SRT/RTP protocols
- Simultaneously decode and output HDMI and SDI signals
- Support for NDI 4.5
- Support for H.264/H.265 video decoders
- Support for AAC/MP3 audio decoders
Web GUI Management
- Provide comprehensive information regarding the device and input signals in real-time
- Allow to configure how an input signal is processed and decoded, including:
- OSD setting, deinterlacing, resolution, frame rate, AR convert, EDID
- audio gain, sample rate and audio channel mapping
- network connection
- Firmware update
- Support USB RNDIS/ECM
- Support IE/Edge/Firefox/Chrome/Safari/Opera web browsers
- Support with HTTP APIs
Supported Web Browsers
- Microsoft Internet Explorer 11
- Microsoft Edge
- Mozilla Firefox version 61 and above
- Google Chrome version 49 and above
- Apple Safari 11.1 and above
- Opera 55.0.2994.44 and above
On-board Control Buttons
- MENU: press to display the menu, or cycle through the options
- SELECT: press to display the menu, enter current option, or confirm the selection
- 16 Position Rotary DIP Switch: set board-index from 0 to F
Network Interfaces
- 10/100/1000Mbps Ethernet
- IEEE 802.3af PoE
USB Interface
- USB2.0 Type B
- 5V/2.1A power supply
- USB RNDIS/ECM
LED Indicator
- Power LED status indicator
- On: power connected
- Off: power unconnected
- Decode LED status indicator
- On: decoding in progress
- Blinks: decoding error
- Off: source unselected
Form Factor
- 100.9mm (L) x 60.2mm (W) x 23.3mm (H)
Accessories
- USB 2.0 A to B Cable
- 5V/2.1A power adaptor
- L-bracket
Screw Mounting Hole
- ¼–20 mounting hole
Power Consumption
- 5V max current: ~1.05A
- Max power consumption: ~5.5W
Working Environment
- Operating temperature: 0 to 40 deg C
- Storage temperature: –20 to 70 deg C
- Relative Humidity: 5% to 90% non-condensing
