Information
Fluid Head incl. Elite Wedge Plate TNG-35, Bowl Clamp BC-2 & Elite Telescopic Pan Bar ELPB-2 (set of 2)
The Elite 25 is the only 150 mm head on the market in this capacity range using an ultra functional spindle drive sliding camera mounting plate, for finer camera plate adjustment. It offers a 12+10 (120) step counterbalance adjustment system, ensuring a virtual perfect balance for any and all payloads. Combined with its assembly (build) lock mechanism and many other practical features, it is
the truly perfect solution for EFP and 4K/HD production, studio applications with full large teleprompter and confidence monitors and compact studio lenses, 3D-rigs and outside broadcast applications.
The Elite 25 tripod systems come with the matching patented Elite 3S-FIX Quick Lock & Release 150 mm 110 kg/243 lbs capacity EFP-HD tripod, illuminated levelling bubble with sliding plate screw parking positions and the integrated screw key to make your operation run smoothly.
Specifications:
| Bowl Diameter | 150 mm / 4-bolt Flat Base |
| Camera Platform Type | Touch & Go 35 |
| Camera Plate | Camgear TNG-35 1/4" screw, 3/8" screw |
| Counterbalance System | 12+10 steps (1-12, 1-10) |
| Pan & Tilt Drag | 10 steps (1-10) |
| Pan & Tilt Range | Pan: 360° / Tilt: +90/-75° |
| Temperature Range | -40°C to +60°C / -40°F to +140°F |
| Levelling Bubble | Illuminated Touch |
| Pan Bar | Camgear Telescopic ELPB-2 (set of 2, left & right) |
| Maximum Payload | 45 kg / 99.21 lbs |
| Weight | 9.58 kg / 21.12 lbs |
| Sliding Range | 120 mm / 4.72 inch |
