DZOFILM Vespid Cyber FF 35,50,75mm T2.1 PL&EF Mount, with Data Interface
- ECO friendly webshop
- Persoonlijk advies
- 25 jaar ervaring
- Meer dan 4.000 producten
- Secure payment
- Registreer en ontdek je voordelen
Specificaties
Informatie
Unique Data Interface Function
Can output the focusing and aperture data which can be applied in post-production and virtual production
Parameters
FOCAL LENGTH 35MM 50MM 75MM
MOUNT PL/EF PL/EF PL/EF
APERTURE T2.1-22 T2.1-22 T2.1-22
IMAGE CIRCLE ∮ 46.5(VV/FF) ∮ 46.5(VV/FF) ∮ 46.5(VV/FF)
FLANGE DISTANCE PL=52mm EF=44mm PL=52mm EF=44mm PL=52mm EF=44mm
CLOSE FOCUS
[ FROM SENSOR PLANE ] 0.3m / 1ft 0.46m / 1.6ft 0.6m / 2ft
IRIS CONTROL 63° 58° 68°
FOCUS CONTROL 270° 270° 270°
FRONT DIA. φ95 mm φ95 mm φ95 mm
LENGTH 97mm 97mm 97mm
IRIS BLADES 16 16 16
FILTER SIZE M86 M86 M86
GEAR PITCH 0.8M 0.8M 0.8M
WEIGHT ≈1.15Kg ≈1Kg ≈1.15Kg
INTERFACE TYPE LEMO(4 PIN) - TYPE C IP 50
